Reach truck 1.4 - 2.5 t

5000 - 14000 mm
1400 - 2500 kg

Compact lithium-ion trucks for maximum throughput.
Fully integrated Li-ion battery with rapid and booster charging function.
Unrivalled productivity thanks to extremely high lift and lowering speeds.
Optional camera system and light strips for high operating comfort.
Semi-automated hydraulic auxiliary functions for increased safety.

ETV 414i–425i

Our innovative and powerful ETV 414i–425i reach trucks are the optimal choice for safe, ergonomic storing and removal with high load capacities and at great lift heights. The fully integrated Li-ion battery makes the truck particularly compact and impresses with its rapid and booster charging capability, as well as extreme flexibility in use. High lift speeds combined with the reachPRO and loweringPRO functions deliver impressive throughput. Smart assistance systems such as active mast oscillation damping or a positioning laser for easier stacking guarantee maximum occupational safety, while tailored operating concepts and a spacious workplace with excellent visibility make a significant contribution to maintaining operator health.

Li-Ion

No worries – no compromise

The Jungheinrich Li-ion Guarantee Plus offers up to 8 years of reliable performance for our high-quality lithium-ion batteries. Confident in their high performance and long service life, we also guarantee a hassle-free switch back to your original technology within 6 months of delivery.

Features

Integrated lithium-ion technology

Extremely short charging times for maximum availability.
Cost savings thanks to extended service life and maintenance-free operation.
Time savings due to the elimination of battery changes.

Enhanced safety

Improved visibility of the support arms and load due to the removal of the lead-acid battery.
Slender roof struts enable optimal all-round visibility.
Drive wheel cover to protect against damage.
Step tread for ergonomic entry into the truck.
Solid shoulder protection.
Optional raised windscreen.
Optional panorama glass roof.
Integrated SmartStripe light strip with daytime running light, brake light, direction indicators and charging indicator, available as an option.
Brake light and direction indicators available as an option.

Wide range of assistance systems and options

Positioning laser for easier stacking of loads.
Permanent monitoring of the limit load capacity via operationCONTROL.
Forks and positioning camera with monitor.

4-inch full-colour display

Travel direction and wheel position indicator.
Battery status with residual time display.
Three selectable travel programs.
Operating hours and time of day.
Optional display of lift height and load weight.

Ergonomic workplace

Extended space for the operator.
Armrest and steering wheel can be adjusted separately without effort.
Entry step for easy entry to and exit from the truck.
Installation of holders for additional equipment such as radio data terminals or scanners is possible.
Practical storage areas.
Comfort charging and optional built-in charger.







Model Overview

Model	Load capacity	Lift height	Travel speed	Overall length	Battery voltage
ETV 414i	1,400 kg	10,700 mm	14 km/h	2,466 mm	51.2 V
ETV 416i	1,600 kg	10,700 mm	14 km/h	2,466 mm	51.2 V
ETV 420i	2,000 kg	14,000 mm	14 km/h	2,477 mm	51.2 V
ETV 425i	2,500 kg	14,000 mm	14 km/h	2,477 mm	51.2 V
